SHENGRUI-Transmission

Shengrui Transmission’s FF8AT, FR8AT and hybrid transmission products feature self-developed core technology and stable comprehensive performance, widely matched with passenger cars, pickups, light commercial vehicles and new energy hybrid vehicles. We are committed to providing customers with high-reliability, fuel-saving and electrification-adaptive automatic transmission solutions.
Choose Shengrui’s full-range automatic transmissions to get smooth, cost-efficient powertrain matching solutions for your vehicle platforms. We keep delivering sustainable value to partners via continuous technical innovation and mature mass production manufacturing processes.

Features of Transmission

  • Modular 8-speed automatic structure including transverse FF and longitudinal FR types, the same platform can be expanded to P2 hybrid transmission FF8HT/FR8HT.
  • Complete torque specifications from 250 N.m to 500 N.m, small gear ratio step difference, prominent fuel-saving performance.
  • Full electronic hydraulic shift control, smooth gear shifting and low operation noise.
  • Forced circulation lubrication matched with integrated thermal management system, working temperature range from -40℃ to 150℃.
  • Multiple optional configurations: electronic shift / cable shift, auto start-stop function, 2WD / 4WD layout, compatible with gasoline and diesel engines.
  • Complete bench test and whole vehicle road verification, high maturity of software and hardware, stable and reliable performance.

HW95508A

The DaTong-Gear HW95508ACL AMT Hybrid Gearbox has external dimensions of 762.2 mm * 464.4 mm * 550 mm, a weight of 148 kg, and an oil capacity of 6L. This gearbox is suitable for light to medium-duty vehicles with a power range between 220 and 300 horsepower.

FIND MORE

DuraMac

DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.

FIND MORE

Fast Gear

The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.

FIND MORE

EV Truck

Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.

FIND MORE

DANA Axle

Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.

FIND MORE

Datong Gear

The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.

FIND MORE

Crane Trucks

The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.

FIND MORE

Find SHENGRUI Transmission by Series

This is the list of all series of SHENGRUI transmission.
Click here to find DaTong gearbox by type (Power & Input Torque).

New Energy Platform DHT500R

New Energy Platform DHT500R

Maximum Input Torque: 500 N.m
Maximum Input Speed: 6000 RPM
Wet Weight: 160 kg
Total Length: 738.4 * 453 * 453 mm

New Energy Platform FR8HT

New Energy Platform FR8HT

Maximum Input Torque: 500 N.m
Maximum Input Speed: 6000 RPM
Wet Weight: 110 kg
Total Length: 786.8 * 413.6 * 416.1 mm

New Energy Platform FF8HT

New Energy Platform FF8HT

Maximum Input Torque: 420 N.m
Maximum Input Speed: 6000 RPM
Wet Weight: 108 kg
Total Length: 414.4 * 411.4 * 629.5 mm

Longitudinal Platform FR8AT

Longitudinal Platform FR8AT

Maximum Input Torque: 250/320/500 N.m
Maximum Input Speed: 6000 RPM
Gear Ratio Spread: 7.8
Overall Length: 621 ± 1 mm

Transverse Platform FF8AT

Transverse Platform FF8AT

Maximum Input Torque: 250-420 N.m
Maximum Input Speed: 4000-6000 RPM
Wet Weight: 80-101 kg
Gear Ratio Range: 3.56 – 3.95/7.09
